EXECUTED PROJECTS & FABRICATION PORTFOLIO

Our Executed Work & Projects

Explore photos and video documentation of our real-world fabrication projects, structural steel installations, lathe machining, and pressure pipeline executions.

Live Workshop Action

Inside Our Tada Workshop & Shop Floor

Watch our certified welders and precision machinists executing heavy turning, MIG/TIG joint welding, and structural steel assembly in our workshop facility.

Featured Project Executions

High-precision engineering solutions delivered across Tada, Sri City, and South India.

Heavy Duty Structural Steel Framework & Beams
Steel Structures
Industrial Corridor, Tada, APCompleted Work

Heavy Duty Structural Steel Framework & Beams

End-to-end shop fabrication and site erection of IS 2062 Grade E350 heavy structural steel framework, built-up H-columns, and crane girders.

Steel GradeIS 2062 E350 / ASTM A36
Fabrication StandardAWS D1.1 Full Penetration Welds
CoatingRed Oxide Anti-Corrosion Primer
Heavy Precision Lathe Turning & Shaft Machining
Precision Machining
Machining Facility, TadaCompleted Work

Heavy Precision Lathe Turning & Shaft Machining

Ultra-precise turning, thread cutting, facing, and boring for heavy power transmission shafts, roller spindles, and custom flanges.

Machining Tolerance± 0.01 mm
Turning LengthUp to 3,000 mm
Surface FinishRa 0.8 µm Smooth Finish
Clear-Span Industrial Warehouse Shed & PEB Roofing
Industrial Sheds
Tada Mandal, Tirupati Dt, APCompleted Work

Clear-Span Industrial Warehouse Shed & PEB Roofing

Turnkey manufacturing plant shed construction featuring Galvalume color-coated profile sheeting, cold-formed Z/C purlins, and turbo ventilators.

Structure TypePre-Engineered Building (PEB)
Roofing Sheets0.50mm Galvalume Color Coated
Wind RatingEngineered up to 180 km/h Wind Speed
High-Pressure Stainless & Mild Steel Pipelines
Pressure Piping
Chemical & Process Plant, APCompleted Work

High-Pressure Stainless & Mild Steel Pipelines

Argon-purged TIG welded SS 316L and carbon steel seamless pressure piping header systems hydrostatically tested for high-fluid steam & gas transport.

Pipe StandardASME B31.3 Process Piping
MaterialSS 316L / ASTM A106 Gr B
Hydro TestTested at 1.5x Operating Pressure (80+ Bar)
Custom Stainless Steel Cleanroom & Sanitary Fabrication
Stainless Steel
Pharma & Food Processing Facility, APCompleted Work

Custom Stainless Steel Cleanroom & Sanitary Fabrication

Fabrication of AISI 304/316 satin finish sanitary vessels, handrails, pass boxes, and cleanroom worktables with full pickling and passivation.

Material GradeAISI 304 / 316 Satin Polish (#4 Grit)
Welding Process100% Argon Shielded TIG Welding
TreatmentChemical Pickling & Passivated
Certified Structural Welding & Custom Metal Fabrications
Steel Structures
Workshop Floor, TadaCompleted Work

Certified Structural Welding & Custom Metal Fabrications

Heavy structural joint welding, gusset plate fitting, machine base plate fabrication, and custom steel enclosures built to exact drawings.

Welding ProcessesMIG (GMAW) & TIG (GTAW)
Inspection MethodVisual & Dye Penetrant (DP) Testing
Quality Audit100% Weld Seam Integrity Verified
Precision Face & Slot Milling for Machine Base Components
Precision Machining
Machine Shop, Tada, APCompleted Work

Precision Face & Slot Milling for Machine Base Components

High-precision face milling, T-slotting, and multi-axis drilling for custom gearbox housings, tooling fixtures, and heavy base plates.

Milling Tolerance± 0.02 mm
Surface Flatness0.03 mm / meter
MaterialCarbon Steel & SS 316
OSHA Compliant Industrial Staircase & Platform Walkways
Steel Structures
Manufacturing Plant, Sri City, APCompleted Work

OSHA Compliant Industrial Staircase & Platform Walkways

Design and installation of heavy-duty MS chequered plate staircases, fire escapes, and safety guardrails engineered for high live-load safety.

Code StandardOSHA & IS Structural Code
Step TreadsChequered Anti-Skid Plate
FinishEpoxy Primer & Powder Coating
Heavy Load-Bearing Structural Steel Beams & Girders
Steel Structures
Commercial Complex, Tirupati DtCompleted Work

Heavy Load-Bearing Structural Steel Beams & Girders

Precision cutting, beveling, and stiffener plate welding for ISMB 600 beams and wide-flange H-girders supporting crane runway tracks.

Beam ProfilesISMB 600 & Built-Up H-Girders
Steel GradeIS 2062 E350 Grade
ConnectionsHigh-Tensile Bolted Flanges
SHOP FLOOR GALLERY

Fabrication & Machining Photo Gallery

Snapshots of structural steel components, machining parts, welded seams, and assembly work at our shop.

Heavy Structural Steel Beam Assembly
Steel Structures
Heavy Structural Steel Beam Assembly
Precision Shaft Turning & Lathe Machining
Lathe Machining
Precision Shaft Turning & Lathe Machining
PEB Warehouse Industrial Shed Construction
Industrial Sheds
PEB Warehouse Industrial Shed Construction
High-Pressure Steam & Gas Pipeline Joint
Pressure Piping
High-Pressure Steam & Gas Pipeline Joint
SS 316 Sanitary Cleanroom Vessel Fabrication
Stainless Steel
SS 316 Sanitary Cleanroom Vessel Fabrication
Seamless Steel Pressure Pipe Flange Fitting
Pressure Piping
Seamless Steel Pressure Pipe Flange Fitting
AWS Certified Heavy Structural MIG Welding
Welding
AWS Certified Heavy Structural MIG Welding
Argon Purged TIG Weld Seam Inspection
Welding
Argon Purged TIG Weld Seam Inspection
Micrometer Precision Shaft Concentricity Audit
Lathe Machining
Micrometer Precision Shaft Concentricity Audit
Galvalume Roof Truss & Purlin Alignment
Industrial Sheds
Galvalume Roof Truss & Purlin Alignment
Custom CNC Machined Steel Base Brackets
Milling Machining
Custom CNC Machined Steel Base Brackets
High-Pressure Heavy Steel Flange Connection
Pressure Piping
High-Pressure Heavy Steel Flange Connection

Have a Metal Fabrication or Machining Project?

Send us your CAD drawings or site measurements for a fast, competitive technical cost estimate.
